!!!This is a downloadable product. Buy it once and then download it all the times you want! I hope you understand this is NOT the assembled PCB. You receive the GERBER files for the board and information for everything you need to make this version of tNoobix IoT control board.

*Once you make the order, go to my account → DOWNLOADS,  select the order and then click the Download link on the right side and the file will be downloaded in a .ZIP file.

Specifications

1. Model Name: Noobix
2. Version: 1.3
3. Size: 70mm*30mm
4. PCB weight: <5g
5. Soldermask color: Any
6. PCB Thickness: 1.2mm
7. Input voltage: 220V AC
8. LOAD voltage: 220V AC / 2A
9. Connections: UART / WiFi
10. Operating temperature: -40 Celsius to +85 Celsius

Characteristics

1. WiFi Connection
2. SSR Control over IoT
3. Database connection
4. Arduino Compatible
5. POST Method (secure)
6. Read/Write to database

Package includes:

1. 1 x GERBER files for PCB V1.3
2. 1 x Schematic
3. 1 x Website PHP files
4. 1 x Arduino Firmware (22/10/2022)
5. 1 x Full Tutorial HERE

Video Here

Part List

1. 1 x ESP32S Wroom: LINK Aliexpress (scarcity in 2022)
2. 1 x SSR relay 5V: LINK Aliexpress
3. 1 x 220V – 12V 1000mA Converter: LINK Aliexpress
4. 1 x S8050 NPN: LINK Aliexpress
5. 1 x M4 diode: LINK Aliexpress
6. 1 x AMS1117 5V: LINK Aliexpress
7. 1 x AMS1117 3.3V: LINK Aliexpress
8. 2 x 2Pin screw terminal: LINK Aliexpress
9. 3 x 0603 LEDs: LINK Aliexpress
10. Female PCB Pins: LINK Aliexpress
11. 4 x 1206 10uF Capacitor: LINK Aliexpress
12. 3 x 0603 100nF Capacitor: LINK Aliexpress
13. 4 x 0603 10K Resistors: LINK Aliexpress
14. 1 x 0603 1K Resistors: LINK Aliexpress
15. 2 x 0603 330R Resistors: LINK Aliexpress
16. FTDI UART Module: LINK Aliexpress
